The complex part—of the latest and greatest lightweight, super-strong well-oiled material, formed in multiple stations, punched and bent under the watchful eye of myriad sensors—exits the press in pristine condition within exacting tolerances. The technology that makes it all possible is dizzying, but such an ideal part cannot be produced without the efforts of the first link in the production chain. It all starts with the press feed.
No one knows that better than Chris Crider. Chief engineer at P/A Industries, Inc., Bloomfield, CT, Crider has three decades under his belt designing and improving press-feed systems. He’s witnessed the evolution of servo motors and controls that have enabled new levels of feeder precision and performance, and has offered MetalForming his insight into what today’s press feeds can do.
Servo-Motor Performance Spells Improved Feeding
“Years ago, when servo motors debuted, metalformers buying servo-driven press feeds were trying to solve the problems they had in their tooling, and a servo feed was not always a fix,” Crider recalls. “If a mechanically driven unit had a problem feeding accurately, chances are the servo did, too.”
Press-feed systems are much more capable than the offerings of years past, and advances in control capabilities have played a big part. Just as importantly, servo motors, too, have evolved. For example, “on a stamping press, a feeder is subjected to a lot of shaking and vibration, and must perform in all kinds of nasty environments,” explains Chris Crider, chief engineer at P/A Industries, Inc. “The encoder systems on servo motors have become more robust, as have the motors themselves, to better handle that shock and vibration.”
Then again, back then servo motors were no bargains themselves.
“Servo drives were unstable or not tuned correctly for the material running through them,” says Crider. “That caused problems with accuracy and stability. But over the years, servo suppliers have gotten much better at providing motors with accurate control—the resolution of the servo motor, how accurately it can be positioned, and how easily it can be tuned.”
The newer generations of servo motors also are much heartier.
“On a stamping press, a feeder is subjected to a lot of shaking and vibration, and must perform in all kinds of nasty environments,” Crider continues. “The encoder systems on servo motors have become more robust, as have the motors themselves, to better handle that shock and vibration.”
The increased use of gag tooling in presses, where material must be indexed in multiple, not just single, fixed lengths, owes to improved servo-motor performance and the advances in the resolution of encoders within those motors.
“By alternating the indexing lengths, unique actions can be performed in the tooling, allowing additional processes to occur in the press,” Crider says. “That indexing is controlled by the feeder, allowing punching to occur in sequence with the indexing.
“With a standard progressive die where feed length does not vary,” he continues, “pilot pins in the die locate the part material. But as soon as a stamper is running multiple feed lengths, the process must rely on feeder accuracy to control material placement and ensure part accuracy.”
Improved Controls, Communication Ease Press-Line Fit
“Feeders now can talk to the press control and share information, and incorporate job and tool storage,” notes Crider. “From the press control, feeders can be programmed for index length, when to index and a host of other parameters, all set and available for recall.
“We always are asked about increasing capacity for job storage,” he continues. “Before, an operator would dial in a feed length and set acceleration and the feeder would be ready. Now, when the job number is called up on the press control, feed parameters change automatically.”
This ability makes newer press feeds ideal components in press lines tasked with shorter runs with a variety of jobs using a variety of material types and thicknesses. In short, feed systems will not compromise setup time in any way. With such simple operation, an operator is not required to be a feed-system expert, and the feeder does not have to rely on constant user input to achieve and maintain accuracy and performance.
For fit to a press line, a feed system only requires a power source and an interface with the press control, be it serial communication or an Ethernet connection.
“With a simple control, the feed system is looking for a switch that tells it when to index, and another to tell it when to open the rolls for piloting,” says Crider, explaining how feed systems typically interact with the press control. “More modern controls deliver a host of information from the press via the job number, so all of the needed parameters are supplied.”
As material is threaded, strip can be jogged by hand or through the feed rolls, powered courtesy of a jog button on the control that allows precise setting of indexing. This eases setup for the first time a job is run, and, again, those parameters are saved for future recall. In addition, during operation, special features in newer-generation servo-driven feeds enable acceleration/deceleration ramping and feed-angle adjustment to minimize strip jerking or slippage, which also improves accuracy.
Should positioning of the strip somehow become compromised, instead of producing bad parts the feed system can stop the line and issue a fault message. Of course, it will stop automatically should any sensors in the press or die note a discrepancy and communicate a stop order.
