and with bed lengths to 84 in. Many of Kenmode’s presses employ electronic servo feeds to reduce setup times and prevent misfeeds.
Press Technology Meets Medical Demands
Mechanical-press manufacturers have gone to great lengths to evolve technologies that deliver, at high speeds, precision parts such as those needed to satisfy demanding medical customers.
Refinements have addressed proper distribution of the load acting on the press ram. This includes designing absolute minimum clearance in the main and connecting-rod bear- ings. To prevent deflection of a tool’s upper die due to eccen- tric loads, presses may have ram-guide elements placed in the same plane as the strip. Besides protecting the press and helping to ensure precision, quality parts, this design can decidedly increases a tool’s service life.
More responsive clutch and brake units deliver minimized braking distances. And, short braking angles designed into some presses produce an almost immediate stop of the punching process when, for example, a stop is triggered by the tool-monitoring system. Refinements such as these pro- tect presses and tooling, and go a long way toward first- to last-part accuracy.
What You Need to Succeed in Medical
To best serve manufacturers of short- or long-term implantable medical and surgical devices, metal stampers must offer these advanced capabilities.
1) Quick rapid prototyping of metal stampings
Delivering a new Class III medical device to market can be arduous, so speed is of the essence. When developing a new product, manufacturers seek suppliers that can provide prototypes faster than ever before. Due to the complexity of metal-stamped parts, in the past prototyping typically has taken from two to four weeks. Now, OEMs want stampers to produce prototypes in a matter of days. To deliver in such a short timeframe, metal stampers should have a dedicated prototype and R&D unit.
At the same time, OEM engineers want layouts of the prototype’s critical dimensions in order to know if it differs from the expected production part. A reliable working pro- totype of the device is important so that clinicians can test it with a realistic look, feel and function.
2) Deign for manufacturability with simulation software
Hand in hand with prototyping is design for manufac- turability. Metal-stamping firms can add tremendous value when their engineers are involved early on in the design phase by working with the OEM’s team on part design. With the move toward miniaturization of implantable devices, metal stampings are becoming smaller and more complex. At the same time, some of the specialty metals used in
implantable devices, such as titanium, can be difficult to form in a stamping. Before the design of a metal stamped part is finalized, the metal stamper’s engineers should be consulted. The engineers often can suggest improvements to the design that can eliminate secondary operations or reduce the use of precious metals and related costs.
Metal-stamping firms that work with innovative product designs rely on finite-element-analysis simulation software to determine how a part design will perform in production. For a new part design that may test the limits of metal stamping, engineers may run any number of different iter- ations of a simulation, showing how a tool will form a part and whether the metal specified will work within those limits. This capability can also speed prototyping by elimi- nating multiple iterations of prototype parts in favor of those most likely to succeed.
3) Inhouse tooling capacity and precision-metal-stamping capabilities
Metal stampers should demonstrate their expertise in precision stamping through their ability to build and main- tain the customized tool inhouse. In the past, the process of designing and building a tool has taken anywhere from 8 to 14 weeks, depending on the project. Now, OEMs may require a working prototype tool in less than a week. While that compressed timeframe is not always possible with a complex stamping that requires a progressive die, new tech- nologies allow many metal stampings to be formed with a single-stage die set.
4) Specialized quality systems for implantable and surgical devices
The implantable and surgical medical-device industry must navigate the toughest government regulations in the world, courtesy of the U.S. Food and Drug Administration (FDA). For that reason, a stamper should be ISO 13485 cer- tified and possess a quality system that matches the spe- cialized needs of the medical-device manufacturer. Such a stamper also should be aware of FDA 21 CRF820.3 and qual- ity-system regulations.
A stamper should work with stringent validation protocols that follow the IQ/OQ/PQ process to ensure that critical- to-function dimensions are held for the new part. During production, advanced metal stampers rely on in-die sensor technology and digital inspection equipment for real-time quality control.
Redundant presses of the same tonnage and manufacturer parameters also are important in order to ensure uptime. To avoid having to revalidate a new press in the event of a mechanical failure, stampers can validate two or more of the same presses with the die. Having multiple presses is an important factor in risk mitigation and ensuring a steady supply of parts, without the need for a change order.
For more, visit Tim Lynch’s medical-related blog posts at www.kenmode.com/blog. MF
