strength ratios (such as low-strength aluminum alloys) require much tighter clearances, making chipping, wear and abrasion more problematic. Also, small variances in cutting clearance—as little as 0.5 percent material thickness per side—can have a dramatic effect on burr height, sliver production and tool wear.”
Springback compensation for high- strength steels and aluminum alloys also deserves careful attention, and Ulintz will address this during his pres- entation. And, some product and addendum geometry suitable for deep drawing of mild steel will not work for many aluminum alloys.
“Simple things like draw-bead pro- file design requirements can vary great- ly between temper grades within a sin- gle alloy,” he says.
Introduction to Simulation Technology
This presentation, by Jeanne He- Dubois, Dynaform Product Manager, ETA—Engineering Technology Associ-
ates, Inc., covers the two basic simu- lation technologies: the inverse (one- step) method and incremental meth- ods. Up for discussion:
• Simulation of drawing, springback, springback compensation, hydroform- ing, forging, trimline development, superplastic forming and hot forming.
• Advantages and limitations of sim- ulation software.
• Differences between incremental and one-step solvers.
• A discussion of the explicit and implicit simulation methodologies, and element/time-step/mass scaling/dy- namic effects.
“With increases in computing speed,” He-Dubois says, “the inevitable trend is the merging of simulation into the CAD environment. Designers now use sim- ulation technology directly as they design a tool. Some CAD packages already have merged one-step analysis into their design flow, and it’s just a mat- ter of time before incremental analysis will be inside of every CAD package.
“Full time simulation-engineer posi- tions are shrinking quickly,” she adds. “I will discuss the impact this trend will have on the industry.”
Next-Generation Simulation Leads Engineering
Beyond Just Validation
Adithya Ramamurthy, an applica- tion engineer at AutoForm Engineering USA, follows up with a discussion on using virtual simulation to identify potential forming issues that might occur during tryout and production. A subsequent trial-and-error approach can lead to identifying solutions to the forming issues encountered during evaluation of a simulation.
“The trial-and-error approach might work well for minor fixes or when a seasoned tooling engineer uses his vast experience for known issues,” Rama- murthy says. “It is a well-established fact that the trial-and-error approach, both in the toolroom and during sim- ulation, can waste time and resources.
