of the influences of variables such as friction, material properties and work- piece geometry on process mechanics, it is impossible to adequately design dies much less predict and prevent the occurrence of defects.
To address this deficiency, metal- formers can turn to process simula- tions, which make science-based man- ufacturing knowledge readily available early in the die-design phase (Fig. 2). Now, the die engineer or designer can submit a design concept and try it out on the computer before developing the final design. This provides an oppor- tunity to make process improvements while evaluating process-sensitive vari- ables. The designer can accept simu- lation results, or he can repeat the sim- ulation process with new input parameters until establishing an acceptable process.
Perhaps the greatest advantage of metal-stamping simulations is the abil- ity to see the blank deform in small, incremental steps in a “see-through” die. How often have you encountered a problem with a tool in the press shop and tried to watch what happens as the press slide inches down? Eventually, you lose sight of what’s happening as the die closes.
Wouldn’t you have a better oppor- tunity to solve problems and evaluate the robustness of a design if you could see what was happening inside of the die? Stamping simulations allow us to do just that. If necessary, the designer can select and evaluate an entirely dif- ferent design path because the impact on project cost and timing is minimal in the absence of a hard die design.
In contrast, the designer all too often submits a die design—without the ben- efit of stamping simulation—to the tool shop for build. The die reaches the tryout press and for the first time results are available for a stamping process that was developed four to six months earlier. If the results fail to meet expectations, we surely will hear those dreaded words once again, “If we only knew...” MF
