Tech Update
Control Upgrades Give Peening Machines a Shot in the Arm
Boeing has learned first-hand how a control-system upgrade can make an old machine work like new, at a fraction of the cost of purchasing a new machine. Case in point: recent refurbishing of four shot-peening machines at the Boeing Fab- rication Division plant in Auburn, WA. The Boeing fabrication shop uses spanwise peening machines for contouring wing components, and compression peening machines for cold working. Early in 2011, plant managers decided to upgrade the machines’ controls, which ranged from 20 to 40 years old. Some used relay logic and some were CNC-based. Parts had become obsolete, and maintenance had become overly expensive.
The plant’s managers sought new controls that were more process-orient- ed, and simple-to-use human-machine interfaces (HMIs) standardized with oper- ator controls used at other Boeing plants. To help with the upgrades, Boeing turned
to Concept Systems Inc. Albany, OR, and its engineer Jim Ford, who proposed replacing the old CNCs with Allen-Bradley PLCs. In addition, he recommended Allen-Bradley Panel View terminals to provide the graphics displays. The old DC servos were replaced with smaller AC ser- vomotors and new gearboxes were installed to upgrade the mechanical aspects of the machine.
Describing the first machine to be upgraded—a 30-yr.-old spanwise unit experiencing the most downtime of the four machines—Boeing equipment engi- neer Franklin French says: “The shot peeners are akin to self-destructing machines. There’s armor plating in the machine to protect the chamber, but when we opened up the old machine, we found shot inside the wheel servomotors, ultimately requiring a replacement of the motors and shrouding.”
During the upgrade, to help minimize
maintenance problems the new motors were equipped with vibration transducers and temperature sensors to provide advance warning of failures. Also, Concept Systems designed the HMI to display tem- perature and vibration levels and historical trends. New armor plate shrouding pro- vides optimum protection of the motor parts, and the homing limit switches were replaced, improving reliability.
To facilitate programming of the span- wise peening machine, Ford wrote a custom Visual Basic program that reads an Excel spreadsheet containing the required process parameters. “Since Rockwell supports only three axes of coor- dinated control and we needed five axes to implement the shot controls,” says Ford, “we needed to use a little creativ- ity to make the five axes look like three to the PLC.”
Further, to improve machine safety, Concept Systems added safety relays and
