another feature along with diagnostic information for more than 300 alarm codes. The software helps pinpoint alarm causes then prompts the user through steps necessary to correct them, min- imizing robot downtime.
For repair procedures, the software includes instructions, photographs, drawings and schematics for lubrication as well as for motor, servo-pack and fuse replacement. Also included: wiring diagrams, exploded parts views, part numbers and spare-parts lists.
The model-specific software, available on a yearly subscription basis but free for trial and evaluation, requires a high-speed Internet connection and a PC with compatible web browser. Addi- tional robots can be added to the software at a fraction of annu- al subscription cost.
Motoman Inc.: 937/847-6200; www.motoman.com
Six Criteria for Making the Move to Fourslide
Named for the four tool slides that perform stamping and forming operations, the fourslide process offers several poten- tial benefits over the traditional mechanical stamping press. Among its advantages: the cost-effective manufacturing of com- plicated forms, reduced production expenses, speedier prod- uct delivery and wide latitude to modify forms without a steep monetary penalty. The following considerations can help an engineer determine when to consider the use of the fourslide metalforming process.
Fourslide manufacturing begins with the raw material in flat strip off of a coil, which is stamped or blanked in the progressive die section of the fourslide machine. The strip then feeds into the forming section, where four tool-carrying slides approach the part and form the material around a central tool or man- drel. The setup of the machine cams determines the sequence, timing and number of tool strikes.
The fourslide forming tools can be machined for a fraction of the cost of complicated stamping dies. As a result, the price for fourslide tooling typically registers at just a fraction of that for stamping tools. Says Anthony Viggiano, co-owner of Autotether, Inc., Rocky Hill, CT, which manufactures multi-func- tional wireless alarm switches for boating safety applications:
“People become reticent about spending a lot of money on a stamping tool because the payback could extend to 10 years due to slow sales. But with the fourslide process, the cost of the tool isn’t that great, so our up-front capital investment isn’t high.”
Don Schmidt, a manufacturing engineer with Kaba Mas, Lex- ington, KY, which makes high-security locking devices that employ fourslide parts, adds: “We have had situations where we’ve quoted a metallic part with some forms, both from con- ventional stamping houses and from fourslide houses. We’ve always done better with fourslide in terms of cost. I always look at the complexity of the part, and for complicated forms and
Hard-pressed when it comes to weight and strength?
AP&T is with you every step of the way – from cold blanks to
hot parts. We deliver complete production solutions for press
hardening of sheet metal parts with a weight-
to-strength ratio that is hard to beat. Not only that, but
we also take total responsibility for everything working – a fundamental concept we call One Responsible
Partner®. Read more at aptgroup.com.
spring-type
parts it makes sense to utilize a fourslide operation.”
Because of its unique
integration of compound
forming operations, the fourslide
process can execute multiple bends, bends
beyond 90 deg., twists, cylindrical forms and tapped holes before the part is ultimately ejected.
“You can’t bend a part beyond 90 deg. with a mechanical stamping press unless you add something to the tool that has actuating mechanisms,” explains Jim Richards, director of mar- keting for Fourslide Spring and Stamping, Inc., Bristol, CT. “With all of the extra cams, lever arms and cylinders, a stamping die can become complicated, expensive and costly to maintain. On the other hand, the fourslide process can easily perform addi- tional bends with the second, third, fourth or even a fifth slide, each of which carries a tool block.”
Making part revisions also proves relatively simple with fourslide tooling. Viggiano recalls a case where the firm had to revise a fourslide tool, to the tune of only about $1000. “This is typical for fourslide tools,” he says. “If it had been a progressive die, the revision would have cost more like $10,000.”
Adds Schmidt: “With a progressive die or conventional stamp- ing tool, you have only one cycle at the press, so all of your tool- ing has to be timed within the die in that one stroke—a change might require retiming the entire tool. However, with four sep- arate slides, the metalformer can easily adjust each station indi- vidually. This provides flexibility in controlling the different oper- ations to effect any necessary design changes.”
As a general rule of thumb, any material less than 2 in. wide, less than 0.075 in. thick, and within 15 in. in blank length can be formed using the fourslide process.
Fourslide Spring and Stamping Inc.: 800/832-6405; www.fourslide.com
